PURROS PG-600F Universal Tool Grinder, Worktable Diameter: 300mm, Traveling Schedule: 150mm, Grinding Wheel Size: 125×50×32mm

Description

Description

PG-600F Universal Tool Grinder, Scoring Blade Sharpening Machine, Grooving Cutter Sharpening Machine Manufacturer.

Universal Tool Grinder PG-600F

ADVANTAGES

  1. The working table uses the dovetail guide rail, good rigidity, steady bed platform, dexterous operation.
  2. Motor can rotate 360° in the horizontal plane, the grinding wheel can be clockwise and anticlockwise rapidly. When grind different kinds of material’s cutter, you can turn the grinding wheel, which can add the safety and reduce the time of replacing and dressing the grinding wheel, adding controllability of cutter grinding.
  3. Grinding is a delicate process among the different types of machining operations. This operation helps to obtaining finishing to the work material.. This device stays very effective for performing complicated grinding.

Universal tool grinder application

PURROS PG-600 universal tool grinder application include reamer, screw Tap, twist drill, reamer bit, milling cutter, cutter head, gear shaper cutter.

PURROS PG-600F universal tool grinder application include reamer, screw tap, twist drill, reamer bit, milling cutter, cutter head, gear shaper cutter.



Model: PG-600F
Stroke of Workable (X-axis): 300mm
Stroke of Workable (Z-axis): 150mm
Worktable Size: 130*520mm
Rotating Angle of Grinding Wheel (Horizontal): 360°
Grinding Wheel Size: 125*50*32mm
Grinding Wheel Speed: 2800RPM
Grinding Motor Power:  3/4HP,  220V/380V
Dimension: 700*630*630mm
Net Weight/Gross Weight: 160kg/175kg
Standard Model (Grinding Attachment): 50C, 50H can grind slot miller, face and side cutter, lathe tool,

hobbing cutter, reamer bit etc.

Optional Model (Grinding Attachment): 50E grind spiral milling cutter ball end mill,R type lathe tool,

graver and other taper milling cutter.

50K can grind drill bit ,screw tap,side mill,round bar and so on.

50D can grind end mill ,side mill and so on.

50B tablebox

50J thimble

The worktable of PG-600 uses the dovetail guide rail, good rigidity;
And PG-600F uses two high precision straight line roiling guide rails, steady bed platform, good movement. PG-6025 can grind in hole and outer annulus.
Standard accessories can grind slot miller, face and side cutter, lathe tool, hobbing cutter, reamer bit etc.
Choosing 50E can grind spiral milling cutter, ball end mill.
Choosing 50K can grind drill bit, screw tap.



Model: PG-600/PG-600F PG-6025
Stroke of Workable (X-axis): 300mm 350mm
Stroke of Workable (Z-axis): 150mm
Worktable Size: 130*550mm 130*680mm
Grinding Wheel Size: Φ125*50*Φ32mm Φ150*16*Φ32mm
Grinding Wheel Speed: 2800RPM 5000RPM
Power: 3/4HP, 220V/380V
Dimension: 700*630*630mm 730*710*715mm
Weight: 165kg 222kg
